ANSYS SCADE Suite

Integrated design environment for critical applications including requirements management, model-based design, simulation, verification, certified code generation and interoperability with other development tools and platforms.

SCADE Suite

Overview

ANSYS SCADE Suite is a product line in the ANSYS embedded software family that provides you with a model-based development environment for reliable embedded software. With native integration of the formally defined SCADE language, the SCADE Suite is the integrated design environment for critical applications including requirements management, model-based design, simulation, verification, qualifiable/certified code generation, and interoperability with other development tools and platforms.

The SCADE Suite is a vital tool for designing mission-critical software, including flight control and engine control systems, automated pilots, landing gear systems, as well as power and fuel management systems, cockpit displays, rail interlocking systems and signaling, automatic train operation, computer-based train control, over-speed protection, emergency braking systems, train vacancy detection, nuclear power plant controls, ADAS in cars and many other aerospace, railway, energy, automotive and industrial applications. Ansys SCADE Suite saves verification effort and improves productivity without compromising safety and reliability in critical applications.

ANSYS SCADE Suite drastically reduces project certification costs by simplifying critical control application design and automating verification, qualifiable/certified code generation, and documentation generation. ANSYS SCADE Suite KCG Code Generator is qualifiable as a development tool under DO-178B level A or as a DO-330 TQL-1 tool under DO-178C. It is also qualified under ISO 26262:2011 at ASIL D and C and certified under IEC 61508 2010 at T3/SIL 3 and EN 50128:2011 at T3/SIL 3/4.

TECHNICAL SPECIFICATIONS

  • Software Prototyping and Design
  • Advanced Model-Based Design
  • Timing and Stack Size Optimization with Timing and Stack Optimizer1
  • Java-Based Eclipse API and TCL API
  • Debugging/Simulation with SCADE Suite Simulator
  • Model-in-the-Loop and Hardware-in-the-Loop Simulation with VeriStand Gateway
  • Automatic Code Generation
  • Development of Embedded Human-Machine Interfaces (HMI)
  • Application Life Cycle Management
