Power Supply Design

Rugged high–performance and independent, battery operated Power Supply designs for mission critical systems that can operate and survive in harsh environmental conditions.

OVERVIEW

Mistral’s COTS and custom power supply designs help system designers reduce size, weight and power (SWaP), as well as the cost, and complexity of various defense sub-systems.

The power electronics modules designed by Mistral offer output power and efficiency, provide internal EMI filtering, support for a wide input voltage range, temperature protection short circuit protection and are MIL-STD-704, MIL-STD-810 and MIL-STD-461 compliant.

EXPERTISE

  • Switch mode and linear
  • AC and/or DC inputs with Power Factor Correction (PFC)
  • Single and Multi-output
  • AC inverters (single and three phase)
  • Analog and Digital Control: TI, Microchip and ST based PWM converters
  • Magnetic Design: Planar, off-line, high power, EMI
  • Power ranges from just a few watts to KW
