The MRD5165 Edge AI Box from Mistral is a high-performance edge AI Engine built around the Qualcomm® QRB5165 SoC. Designed to deliver superior AI computing power at low energy consumption, this edge computer leverages the powerful heterogeneous computing architecture and 5th-Gen Qualcomm® Artificial Intelligence Engine of the QRB5165 SoC. It provides 15 TOPS (Trillion Operations Per Second) of AI performance, enabling efficient processing of complex AI and deep learning workloads for on-device edge inferencing.
Powerful ISP to support multiple concurrent cameras for machine vision applications
Powerful AI/ML NPU to carry out on-board/edge analytics and inferencing on various real-time data gathered.
Efficient low-power DSP to capture and analyze data from various type of sensors.
Varied connectivity options including Long-Range WiFi, 5G, Bluetooth, GigE, etc.
Efficiently processes and decodes multiple concurrent video streams @ 8K 60 fps, aiding robust edge computing.
Power Efficient, high-performance AI/ML, powered by 5th generation Qualcomm® AI Engine, offering 15 TOPS compute power to run complex AI/DL applications.
Support for 6 cameras to be concurrently processed by powerful Qualcomm® Spectra™ 430 ISP and Qualcomm®Adreno™ 665 VPU for advanced Video Analytics
High-efficiency Computer Vision powered Signal Processing and Vision Analytics aided by Qualcomm® Adreno™ 650 GPU and Qualcomm® Hexagon™ 698 DSP.
Robust-compact, energy-efficient, scalable computing device to operate effectively and efficiently in diverse and challenging environments at the edge.
Supports a broad array of high-speed interfaces and connectivity to support a wide range of industrial, robotics, and machine vision applications.
Built to safeguard data; Supports Camera Security, Qualcomm Trusted Execution Environment, Secure Boot, Qualcomm® Crypto Engine Core.
Platform (Qualcomm® QRB5165 SOC)
·      Octa Core Qualcomm® Kryo™ 585 CPU @ 2.84 GHz
·      Qualcomm® Adreno™ 650 GPU
·      Qualcomm® Hexagon™ 698 DSP
·      Qualcomm® Spectra™ 480 Image Processing Engine
·      Qualcomm® Adreno 665 VPU
·      Qualcomm® Adreno 995 DPU
Â
Memory
·      8GB LPDDR5 (PoP)
·      128GB UFS3.1 memory
 ·    SD v3.0 4-bit for SD card
Â
 Camera
·      Up to 6 concurrent cameras – 6x MIPI CSI Ports
·      Video-encode of 4K120/8K30
Connectivity
·      On-Board Wi-Fi 6 (802.11a/b/g/n/ac/ax 2.4/5GHz 2×2 MIMO), BT 5.2/BLE
·      Supports 5G/ LTE (2x Nano SIM support)
·    USB Host port & Type-C (with DP-ALT Mode)
·      Gigabit Ethernet
·       HDMI Input
Â
Expansion Connector
HS Expansion Connector
·       PCIe0 Gen3 1-lane
·       PCIe2 Gen3 2-lane
·       2x USB 3.0
·       2x CSI C-PHY
·    GPIOs
LS Expansion Connector
·       ADC, UART, I2C, SPI, PWM, GPIOs
·       SPI, CAN-FD6
Interfaces
· USB – USB Host Port, USB Device Port
· 4 x UART
· DCAN Connector
· 1GB Ethernet
· SPI/I2C Interface
Debug Interface
· Micro USB Debug Port to access MPU
· JTAG Interface
Generic Specifications
· Power: 12V-36V (12V@5A max) – XT30 Power input
· Form factor: 138 x 92 x 21 mm
· Operating Temperature: -25° C to +80° C
Mistral’s Edge AI-Box, with 15 Trillion Operations Per Second (TOPS) of AI performance, stands out as an exceptionally efficient Edge Computer within the market. Tailored for diverse applications across multiple sectors including smart cities, factories, security and surveillance, retail and warehousing, digital signage, smart grids, and transportation, the versatile Computing platform offers unparalleled performance, and inference at the edge.
The Edge AI-Box seamlessly integrates advanced AI-ML and IoT technologies into a compact form factor, catalyzing innovation in high-compute, low-power smart robots, autonomous machines, and intelligent devices that leverage advanced Computer Vision and Inferencing capabilities at the Edge.
