NVIDIA Jetson Neuron Board

mmWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson NanommWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano

The NVIDIA Neuron Board (Jetson Neuron Board) from Mistral is a feature-rich, performance-oriented base board designed to meet the compelling needs of modern AI, Deep Learning and inference on the edge. Designed to mate with NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX modules, the Neuron Base acts as an NVIDIA Nano carrier board, NVIDIA Jetson TX2 NX carrier board or NVIDIA Jetson Xavier NX carrier board that enables all the features of the SoM for quick product development and benefit meet stringent time to market requirements.

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX Carrier Board

The NVIDIA Neuron Board is available in two Variants – NB Basic and NB Turbo. The NB Basic brings out the required basic interfaces and connectivity features of the NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX SOMs  such as Ethernet, CSI, USB, HDMI, M.2 NVMe Slot, mmWave RADAR etc.
The NB Turbo is richer in terms of additional functional features and interfaces such as GMSL, FPD Link III, Wi-Fi 802.11ac, BT5.0 and 9-axis IMU Sensors.

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Neuron Base Board

mmWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson NanommWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano

NVIDIA Nano Carrier Board

With its highly optimized form-factor, performance-rich I/Os and software support, Mistral’s NVIDIA Neuron Board is a NVIDIA Nano carrier board, NVIDIA Jetson TX2 NX carrier board and NVIDIA Jetson Xavier NX carrier board that offers a flexible and scalable platform to get products to market faster at reduced development cost. Based on a dual board architecture, the NVIDIA Nano carrier board can be mated with NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX SoMs over a compatible SODIMM socket.

NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX Carrier Board

The Neuron Base is designed to enable all the functional features of NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX, NVIDIA Jetson Xavier NX SoMs and aids faster product development and prototyping. It provides I/O accessibility and power to the NVIDIA Jetson Nano, TX2 NX and Xavier NX SoMs.

NVIDIA Nano carrier board is available in two variants namely, NB Basic and NB Turbo.

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

The NVIDIA Neuron Board addresses all crucial requirements that are key to design, develop and prototype embedded edge computing devices, which demand high-performance factors and runs complex AI workloads. The NVIDIA Nano carrier board is ideal for realizing AI-based machine vision applications such as Edge Camera with object detection and recognition, Human Activity Recognition, Robotics, Drones, Autonomous Navigation, Radar-Camera Sensor Fusion and Smart Retail among others. The Neuron Base can be integrated with Mistral’s mmWave Radar Modules (60GHz Industrial Radar or 77GHz Automotive Radar) to design Camera and Radar Fusion Solutions ideal for Industrial and Automotive applications.

The Neuron Board is offered with NVIDIA JetPack SDK, which enables quick development of AI applications utilizing libraries supporting major AI frameworks, computer vision, graphics, multimedia, and more.

HIGHLIGHTS:

NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano, nvidia jetson nano developer kit, NVIDIA Nano carrier board

Scalable
Platform

NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano, nvidia jetson nano developer kit, NVIDIA Nano carrier board

Radar and Camera
Sensor Fusion

NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano, nvidia jetson nano developer kit, NVIDIA Nano carrier board

mmWave Radar
Interface

NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano, nvidia jetson nano developer kit, NVIDIA Nano carrier board

Flexible
Connectivity

Specifications

The Neuron Base can be mated with NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX SoMs over a compatible SODIMM socket.

The Neuron Base is designed to enable all the functional features of NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX, NVIDIA Jetson Xavier NX SoMs and aids faster product development and prototyping.

The NVIDIA Neuron Board is available in two variants.

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Note:

* For Active Cooling, Fan control option is provided

Block Diagram

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board





Neuron Variants

mmWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson NanommWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano

The NVIDIA Nano carrier board / NVIDIA Jetson  TX2 NX carrier board / NVIDIA Jetson Xavier carrier board for NVIDIA Jetson Nano, NVIDIA TX2 NX and NVIDIA Jetson Xavier NX is available in two variants namely NB Basic and NB Turbo.

The NB Basic provides all rudimentary interfaces and connectivity features of the NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX and NVIDIA Jetson Xavier NX SOMs such as Ethernet, CSI, USB, HDMI, M.2 M, mmWave RADAR etc. needed for product development. The NB Turbo is a more sophisticated platform with more functional features and powerful multimedia interfaces such as GMSL, FPD Link III, Wi-Fi 802.11, Bluetooth and 9-axis IMU Sensors.

Based on customer requirements, either variant of NVIDIA Neuron Board can be ordered with Jetson SOM modules as mentioned below.
NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX NVIDIA Nano carrier board NVIDIA Neuron Board



Variants and Pricing Info
NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX NVIDIA Nano carrier board NVIDIA Neuron Board
ADD-ONS

Recommended Modules for Sensor Fusion

To realize Camera-Radar sensor fusion, the following modules can be integrated with NVIDIA Neuron Board.

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board



mmWave RADAR Modules
NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board
Mistral’s mmWave RADAR Modules, based on Texas Instruments single-chip FMCW sensors, enable intelligent and autonomous decision making at the edge! The modules are available in 77GHz and 60GHz frequency bands and are ideal for low power, self-calibrating, ultra-accurate RADAR systems in industrial, Automotive and Smart City Applications.

Model: Mistral’s 60GHz (IWR6843) / 77GHz (AWR1843) RADAR Modules

Link: www.mistralsolutions.com/mmwave



Camera Module (2 lane CSI)
NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board
The camera module with CSI-2 MIPI 2-lane interface from Leopard Imaging is specially designed to mate with NVIDIA Jetson platforms.
Model: LI-IMX219-MIPI-FF-NANO-H136

www.mistralsolutions.com/jetson-camera



Recommended Power Adapter for Neuron Base

Mistral recommend the following 24V/65W and 12V/60W AC/DC power supply adapters that support universal input (90~264 Vac).

Part No: 102-3417-ND [12V/5A Adapter]

www.mistralsolutions.com/adapter12v

Part Number: 102-3418-ND [24V/2.71A Adapter]

www.mistralsolutions.com/adapter24v



AI enabled Sensor Fusion Kit

mmWave RADAR Technology, mmWave Technology, TI mmWave RADAR, mmWave RADAR Modules, mmWave RADAR, millimeter wave radar, NVIDIA Neuron Board, NVIDIA Jetson Xavier NX, NVIDIA Jetson Nano

Overview

The NVIDIA Jetson SoM based AI-enabled Sensor Fusion Kit (AI-SFK) from Mistral is an integrated, performance oriented, Camera Vision and mmWave RADAR fusion platform that meet the compelling needs of modern AI, Deep Learning, and Video Analytics applications.NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

The AI-SFK (Camera Vision + mmWave RADAR) is uniquely designed to provide range precision along with superior imaging capabilities for applications such as ADAS, autonomous vehicle, smart retail, industrial 4.0, robotics, smart building, and smart city among others. The camera & mmWave RADAR complement each other for object detection, classification, range, velocity and elevation parameters. The platform provides vision analytics and RADAR data fusion in real-time.

The Sensor Fusion Kit consists of:

  • Mistral’s Neuron Base Board (NB-Turbo) mated with NVIDIA Jetson Xavier NX SoM
    • Performs object detection, classification and annotates video stream with RADAR range data
  • Mistral’s 77GHz mmWave RADAR Module
    • Consists of FMCW transceiver with integrated PLL, Baseband ADC, R4F controller with accelerator, SPI flash, DSP, etc.
  • Camera Module
    • CSI-based 8 MP / 4K colour sensor supporting up to 21 fps



The platform delivers RADAR point cloud and video data:

  • The RADAR point cloud data consists of object’s ID, range, angle, velocity and signal strength
  • Camera stream inferenced using NVIDIA’s Jetson-inference module & Tensor-RT and annotated for different types of objects
  • Mistral’s Sensor fusion demo algorithm co-relates and combines RADAR target with pre-trained objects (humans)

The SFK also supports NVIDIA JetPack SDK, which enables the development of AI applications with accelerated libraries supporting all major AI frameworks as well as computer vision, graphics and multimedia among others.

Customization

In addition to providing engineering services for product/system development, Mistral provides customization services around SFK for:

  • Custom camera integration
  • Other sensor integration like thermal, LiDAR etc
  • Application software
  • ML/DL algorithms development and integration
  • Remote firmware upgrade
  • Audio and video
  • Cloud and mobile apps
  • PoE
  • Power optimization
  • Mechanical enclosure customization
  • FCC/CE certification support
  • Chirp Profile Tuning support

HIGHLIGHTS:

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Scalable
Platform

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Radar and Camera
Sensor Fusion

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

mmWave Radar
Interface

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Flexible
Connectivity

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

DSP and
Large Memory

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Fusion
Vision Analytics

Specifications

NVIDIA Jetson Xavier NX
NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

  • 384-Core NVIDIA Volta GPU with 48 Tensor Cores
  • 6-Core NVIDIA Carmel ARM v8.2 64-bit CPU
  • 2x NVDIA Engines
  • 7-Way VLIW Vision Processor
  • 8 GB 128-bit LPDDR4x
  • 16 GB eMMC 5.1
  • 10/100/1000 Base-T Ethernet

Camera Module

  • CSI2-2 Lane Camera Interface
  • Sony’s iMX219 from Leopard Imaging

mmWave RADAR

  • Mistral’s 77GHz AoPCB RADAR module based on TI’s AWR1843 SoC
  • FMCW Transceiver with Integrated PLL, Transmitter, Receiver, Baseband and ADC
  • 76 to 81GHz Coverage with 4GHz available Bandwidth
  • Four Receive Channels and Three Transmit Channels
  • C674x DSP for FMCW Signal Processing
  • ARM Cortex R4FBased Radio Control System for Object Tracking and Classification

Storage

  • M.2 M key based 250GB SSD

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board
Network Connectivity

  • Gigabit Ethernet
  • Wi-Fi 802.11 a/b/g/n/ac
  • BT 5.0

Other Interfaces

  • Camera
    • USB
    • 1 x CSI2 – 2 Lanes
    • 1x FPD Link III
    • 1x GMSL
  • USB
    • 2x USB 2.0
    • 1x USB 3.1
  • Display
    • HDMI 2.0
  • Audio
    • HDMI 2.0
    • DMIC / I2S via Expansion Header
  • CAN
  • 9-axis IMU Sensor
  • Expansion Header
    • I2C, I2S, GPIOs, Reset
  • Cooling: Active cooling with Fan
  • Power: 12V/5A to 24V/2.5A
  • Operating Temperature Range: -25 C to 80 C



Sensor Fusion Demo

Object Detection With Ranging demo using Mistral’s AI-enabled Sensor Fusion Kit. The Sensor Fusion Kit integrated with people identification algorithm detects multiple people within a range of approx. 10 meters. The Kit can be integrated with a wide variety of object recognition algorithms to make the Neuron Kit suitable for ADAS, Traffic Management, Smart Building, Smart City and Industrial Automation applications.

Software

Designed to mate with NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX  and NVIDIA Jetson Xavier NX modules, the NVIDIA Neuron Board from Mistral is a feature-rich, performance-oriented NVIDIA Nano carrier board designed to meet the compelling needs of modern AI, Deep Learning and inference on the edge. The Neuron Board supports Ubuntu 18.04 Linux OS. The board supports VisionWorks, a software development package provided by NVIDIA for computer vision and image processing. Mistral also provides TensorRT SDK for high-performance deep learning inference.

  • Supports Ubuntu 18.04 Linux OS natively
  • OpenCV
  • VisionWorks
  • TensorRT
  • LibArgus
  • CUDA

In addition to the above-mentioned software, the AI-SFK board also supports:

  • CuDNN
  • ROS1 Melodic
  • RADAR / Camera Fusion



NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Infographic

Designed to mate with NVIDIA Jetson Nano, NVIDIA Jetson TX2 NX  and NVIDIA Jetson Xavier NX modules, the NVIDIA Nano carrier board and NVIDIA Xavier NX carrier boards from Mistral are a feature-rich, performance-oriented base board designed to meet the compelling needs of modern AI, Deep Learning and inference on the edge.

NVIDIA Jetson Nano, NVIDIA Jetson Xavier NX, NVIDIA Jetson TX2 NX, NVIDIA Nano carrier board, NVIDIA Neuron Board

Webinar – Video Vision and Analytics

Date: 15th & 16th September 2021

AI-enabled Video Analytics is changing lives every day; enabling real-time, fast, precise decision-making. NVIDIA’s deep expertise in AI and high-performance computing provides endless opportunities to meaningfully impact the world. NVIDIA’s AI platforms along with Mistral’s Neuron Base make it faster and easier to integrate advanced technologies into applications that are transforming every industry – from Smart Cities and Smart Retail to Robotics and Healthcare.

APPLICATIONS

Edge Camera

Machine Learning

Computer Vision

Object / Image Recognition

Smart Retail

Human Activity Recognition

Industrial Robotics
